YLL coal-fired/biomass thermal oil boiler

  • thermal capacity: 700-2400KW
  • Rated thermal efficiency: ≥87%
  • Pressure: 0.8-1MPa
  • Available fuel: biomass pellets bagasse rice bran bituminous coal anthracite etc.
  • Available industries:

Product introduction

The organic heat carrier boiler is a new type of special boiler, also known as the thermal oil boiler, with low pressure and high temperature working characteristics, and its heating temperature can reach 340°C in the liquid phase or 400°C in the vapor phase.

Organic heat carrier can be used for heating in various production occasions that require uniform and stable heating and do not allow direct flame heating. The heating temperature is between 150°C and 320°C.

Organic heat carrier boilers generally use coal, oil, and gas as fuel and heat transfer oil as the medium. The thermal oil circulating oil pump is used to force the medium to circulate in the liquid phase. The heat energy is transferred to the heating equipment and then returned to the heating furnace for reheating. High working temperature can be obtained under the low pressure, and can carry out high-precision control of the operation of the medium.

The system has high heat utilization rate and convenient operation and maintenance. It is an ideal heating equipment with safety, high efficiency and energy saving.



Production advantage:

1. The boiler adopts the structure of anti-coke collector box, which is located on both sides of the grate and is directly in contact with the burning material layer. As the main heat-absorbing surface at the bottom of the furnace, the purpose is to absorb some heat, adjust the temperature of the fuel layer, prevent coking, and cool the coking slag, which is not bonded to the side wall.

2. Water cooling device (More than 10 ton boiler) is arranged at the coal gate of the boiler to reduce the temperature here and prevent burnt the coal gate. The combustion of the boiler is more stable.3. Compact structure, compared with the same type of boiler, small size, saving boiler room infrastructure investment.

3. Runs steadily and convenient adjustment.

4. The high efficiency and energy saving furnace arch of heat resistant concrete is adopted in the furnace, which improves the fuel ignition condition, adopts independent air chamber, achieves reasonable air distribution, and forms an air power field favorable to combustion in the furnace, thus enlarging the adaptability of fuel.

5. The smoke window at the outlet of the boiler arch has a certain dedusting effect.




Technical parameter

Model YLL-700SCⅡ/AⅡ YLL-1000SCⅡ/AⅡ YLL-1200SCⅡ/AⅡ YLL-1400SCⅡ/AⅡ YLL-1800SCⅡ/AⅡ YLL-2400SCⅡ/AⅡ
Rated thermal power(KW) 700 1000 1200 1400 1800 2400

Thermal efficiency(%)

85 85 85 85 85 85

Design pressure(MPa)

1.1 1.1 1.1 1.3 1.3 1.3
Work pressure(MPa) 0.8 0.8 0.8 1 1 1
Max working temperature(℃) 320 320 320 320 320 320
Furnace content oil volume(m³/h) 0.6 0.8 1 1.2 1.6 2.1
Circulating oil volume(m³/h) 60 100 100 100 100 160
Piping connection caliber(DN) 100 125 125 125 150 150
Appearance size L(mm) 4830 4830 5300 5650 5650 6000
W(mm) 2500 2500 2620 2650 2700 2700
H(mm) 5500 5500 5700 6000 6400 6400
Reference weight(t) 17.5 18 19 20 22 25
